- Processors : 1x HPE DL380 Gen10 Intel® Xeon-Silver 4110 (2.1GHz/8-core/85W)
- Memory : 1x HPE 16GB 1Rx4 PC4-2666V-R Smart Kit
- Hard Drives : Option
- Drive Bays : 8x 2.5" SATA/SAS HS Up to 30x 2.5"
- Raid Controller : 1x HPE Smart Array P408i-a SR Gen10 Ctrlr, HPE 96W Smart Storage Battery 145mm Cbl
- Network Controller : 1x HPE Embedded 1Gb Ethernet 4-port 331i Adapter
- PCI-Express Slots : 3 PCIe 3.0, for detailed descriptions reference the QuickSpecs
- Optical Drive : Optional USB - DVD±RW
- Graphics : Onboard
- Powe Supply : 1x HPE 500W FS Plat Ht Plg LH Pwr Sply Kit
- Rail Kit : HPE 2U SFF Easy Install Rail Kit
- Form Factor : 2U Rack
Processor
Intel
Processor family
Intel® Xeon® Scalable 8100 series Intel® Xeon® Scalable 6100 series Intel® Xeon® Scalable 5100 series Intel® Xeon® Scalable 4100 series Intel® Xeon® Scalable 3100 series
Processor core available
28 or 26 or 24 or 22 or 20 or 18 or 16 or 14 or 12 or 10 or 6 or 4
Processor cache
8.25 MB L3, 11.00 MB L3, 13.75 MB L3, 16.50 MB L3, 19.25 MB L3, 22.00 MB L3, 24.75 MB L3, 27.50 MB L3, 30.25 MB L3, 33.00 MB L3, 35.75 MB L3, 38.50 MB L3
Processor speed
3.6 GHz, maximum depending on processor
Maximum memory
3.0 TB with 128 GB DDR46
Memory slots
24 DIMM slots
Memory type
HPE DDR4 SmartMemory
Drive type
8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD 6 SFF rear drive optional or 3 LFF rear drive optional and 2 SFF rear drive optional 20 SFF NVMe optional NVMe support via Express Bay will limit maximum drive capacity
Infrastructure management
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (optional)
Power supply type
2 Flexible Slot power supplies, maximum depending on model
Expansion slots
8, for detail descriptions reference the QuickSpecs
Network controller
HPE 1 Gb 331i Ethernet adapter 4-ports per controller and/or optional FlexibleLOM, depending on model
Storage controller
1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a and/or 1 HPE Smart Array P816i-a and/or 1 HPE Smart Array E208i-a, depending on model
System fan features
Hot-plug redundant fans, standard
Form factor
2U
