0₫
• Cổng Ethernet 10/100/1000 : 24 cổng.
• SFP : 2 cổng
• Hiệu suất : 26 Gbps
• Nguồn tiêu thụ tối đa: 250W
• Hổ trợ nguồn POE+ IEEE 802.3at/af
• Cấp nguồn: 100-240VAC/50-60 Hz
• Lắp đặt trên giá đỡ 1U
Bảo hành: 12 tháng
Dimensions | 485 x 43.7 x 285.4 mm (19.09 x 1.72 x 11.24") |
Weight | 4.7 kg (10.4 lb) |
Power Method | 100-240VAC/50-60 Hz, Universal Input |
Power Supply | AC/DC, Internal, 250W DC |
Maximum Power Consumption | 250W |
Certifications | CE, FCC, IC |
Operating Temperature | -5 to 40° C (23 to 104° F) |
Operating Humidity | 5 to 95% Noncondensing |
Total Non-Blocking Throughput | 26 Gbps |
Switching Capacity | 52 Gbps |
Forwarding Rate | 38.69 Mpps |
Management Interface | (1) RJ45 Serial Port, Ethernet In/Out Band |
Rackmount | Yes, 1U High |
Shock & Vibration | ETSI300-019-1.4 Standard |
Max. PoE Wattage Per Data Port | 34.2W |
LEDs Per Port | PoE, Speed/Link/Activity |
ESD/EMP Protection | Air: ±24 kV, Contact: ±24 kV |
Supported Voltage Range | 50–57V |
Networking Interfaces | (24) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1 Gbps SFP Ethernet Ports |
PoE Interfaces | POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-) 24VDC Passive PoE (Pins 4, 5+; 7, 8-) |
Max. Passive PoE Wattage per Port | 17W |
Passive PoE Voltage Range | 20-27V |
